Main features:

• 9 kHz-40 GHz real-time spectrum analyzer
• Superheterodyne digital receiver architecture, 14 segments pre-selected filter
• 9 kHz~40 GHz typical image suppression >75 dBc, typical IF rejection>75 dBc
• 100 MHz analysis bandwidth with adjustable sampling rate, 291.6 GHz/sec sweep speed
• FPGA based digital signal processing
• Weight 660 grams, size 167×117×28 mm, power consumption: 18 W
• 1000M/100M Ethernet interface
• Build-in multimode GNSS
• Provides 1PPS, latitude and longitude information and timestamp
• Highly compatible API interfaces and SAStudio4 GUI
• Remote master of ARM and x86 processor are supported
• Linux and Windows are supported
• Operating temperatures range from -20 ℃/-40 ℃ to 65 ℃ (option)
• Built-in OCXO (option) or GNSS disciplined OCXO (option)
• Built-in 4G data module (option)
