Main features:

• 9 kHz~6.3 GHz real-time spectrum analyzer/receiver
• Integrated 100 kHz-6.3 GHz analog signal generator (option)
• 100 MHz analysis bandwidth, 300 GHz/sec spectrum sweep speed
• FPGA based digital signal processing
• 1GHz phase noise: -114 dBc/Hz@10kHz
• 1GHz DANL: -167 dBm/Hz
• Weight 168 grams (core module), size 142mm×54mm×16mm, power consumption 7-10 W
• Highly compatible API interfaces and SAStudio4 GUI
• Compatible with ARM and x86 processors, Linux and Windows operating systems
• Operating temperatures range from -20 oC/-40 oC to 70 oC (option)
• Built-in OCXO (option), temperature drift≤0.15 ppm
• USB3.0/2.0 Type-C interface
