Main features:

• 9 kHz~20 GHz real-time spectrum analyzer/receiver
• Superheterodyne digital receiver architecture, 19segments pre-selected filter
• 9 kHz~9 GHz typical image suppression>90 dB, typical IF rejection>90 dB
• 9 GHz~20 GHz typical image suppression>60 dB, typical IF rejection>90 dB
• 100 MHz analysis bandwidth with adjustable sampling rate, 1.2 THz/sec spectrum sweep speed
• FPGA based digital signal processing
• Weight 195 grams (core module), size 125 × 60 × 15 mm, power consumption 10-14 W
• Highly compatible API interfaces and SAStudio4 GUI
• Compatible with ARM and x86 processors, Linux and Windows operating systems
• Operating temperatures range from – 20 ℃/- 40 ℃ to 70 ℃ (option)
• Built-in OCXO (option)
